Topics in this section include:
Overview of the Chassis
Top and Front Panels
The PIX-E5 and PIX-E5H are specically
designed and built for the rigors of eld
production.
The chassis is made of high-strength,
thermally conductive aluminum. As
well as providing maximum durability,
the case doubles as a heat-sink,
providing excellent cooling of the inner
electronics.
By design, the PIX-E chassis gets very
warm, wicking away the heat from
the internal components. This design
ensures that the internal components
stay cool for years of trouble-free
operation in the most demanding
environments.
The top panel features the Power switch, a Power LED, a 1/4-inch, 20-threaded
mounting point, and two retainer clips used to secure batteries and the Speed-
Drive to the back of the monitor.
The front panel has a sunlight-readable, 5-inch LCD that is protected behind an
alkali-aluminosilicate sheet of Gorilla
®
Glass 2, chemically strengthened to be
scratch- and impact-resistant.
Beneath the LCD is a row of buttons, which includes an ALT button on the left,
a MENU button on the right, and in between them, 11 multi-functional soft key
buttons.
Top and Front Panels
Left Side Panel
Back and Bottom Panels
Right Side Panel
To Next Page
