Video Devices PIX-E5 - Audio; Storage

User Guide
66
Supported Input
Resolutions and
Rates
• 4096p30
**
• 4096p29.97
**
• 4096p25
**
• 4096p24
**
• 4096p23.98
**
• 3840p30
**
• 3840p29.97
**
• 3840p25
**
• 3840p24
**
• 3840p23.98
**
• 1080p60
• 1080p59.94
• 1080p50
• 1080p30
• 1080p29.97
• 1080p25
• 1080p24
• 1080p23.976
• 1080i60
• 1080i59.94
• 1080i50
• 1080PsF30
*
• 1080PsF29.97
*
• 1080PsF25
*
• 1080PsF24
*
• 1080PsF23.976
*
• 720p60
• 720p59.94
• 720p50
• 720p30
*
• 720p29.97
*
• 720p25
*
• 720p24
*
• 720p23.976
*
* SDI only, ** HDMI only
Codecs
(Max resolution &
frame rate)
• Apple ProRes 4444XQ, 12 bit* (1080p30)
• Apple ProRes 4444, 12 bit (1080p30)
• Apple ProRes 422HQ, 10 bit (4kp30 / 1080p60 / 720p60)
• Apple ProRes 422, 10 bit (4kp30 / 1080p60 / 720p60)
• Apple ProRes 422LT, 8 bit (4kp30 / 1080p60 / 720p60)
• Apple ProRes 422Proxy, 8 bit (4kp30 / 1080p60 / 720p60)
* SDI Log-encoded inputs only
4K to HD
Conversion
4K input to HD output
Input to le
conversion
• 1080i to PsF
• PsF to P
Video I/O
conversion
• SDI to HDMI
• HDMI to SDI
LCD Display • 5-inch In-Plane Switching (IPS) Liquid Crystal Display (LCD)
• Gorilla
®
Glass 2
• Capacitive touch screen
• 1920 x 1080 pixel resolution with true 16x9 ratio
• 441 ppi
• 179° angle of view
• 500 nits brightness
• 1000:1 contrast ratio
Audio
HDMI 4 channels embedded HDMI input, 8 channels embedded HDMI output
SDI 8 channels embedded SDI input, 8 channels embedded SDI output
Headphone 1/8 in (3.5 mm) TRS with gain control
Line In 1/8 in (3.5 mm) TRS, Unbalanced 2-channel
Sample rate / bit
depth
• 24-bit
• Sample rate synced to active video input (SDI or HDMI). Typically 48 kHz.
Storage
Formats • exFAT drive format (SpeedDrive and SD card)
• Quicktime (.mov) video le format (SpeedDrive)
• XML setup le format (SpeedDrive and SD card)
