Video Devices PIX-E5 - Timecode; Power; Physical; Environmental

67
SPECIFICATIONS
SpeedDrive™ • Internal mSATA Drive
• USB 3.0 interface
• Dimensions (HxWxD): 3.35 in x 1.5 in x 0.5 in
• Weight: 1.2 oz (without drive)
SD card • Types: SD, SDHC, SDXC
i See list of approved media at: www.videodevices.com/approved.
Timecode
Modes Supported • Ext TC (SDI) (RP188)
• Time of Day
• Rec Run
i Start timecode is stamped in the QuickTime le.
Frame Rates 23.976, 24, 25, 29.97DF, 29.97ND, 30DF, 30ND
Inputs • SDI Input BNC
Power
External External 10-34VDC, threaded coaxial connector (5.5mm outer diameter, 2.1mm
inner diameter), pin positive, sleeve negative
Batteries 2x Removable 7.2v (nominal) Sony type L Series Lithium-Ion
Power Draw 12-15W quiescent, depending on settings
Physical
Dimensions
(HxWxD)
3.4 in x 5.4 in x 1.6 in
(8.6 cm x 13.8 cm x 4.1 cm)
Weight 16 oz (1 lb)
Environmental
Operating
Temperature
-10° C to +40° C
