Monitor Soft Keys
When soft key buttons are set for primary monitor functionality, the following
soft key labels appear and the buttons function as described:
LabeL Description
Display Hides or reveals OSD elements: soft key labels and/or the information
bar.
False Toggles on/off the display of the false colors exposure assist tool.
Zebra Toggles on/off the display of zebra stripes exposure assist tool.
4-Way Splits the screen into four quadrants, showing the video image in one
quadrant and three scopes—waveform, vectorscope, and histogram—in
the other three.
WFM Toggles on/off the full-screen display of the waveform monitoring tool.
Vector Toggles on/off the full-screen display of the vectorscope monitoring tool.
Hist Toggles on/off the full-screen display of the histogram monitoring tool.
LUT Toggles on/off the selected LUT.
Zoom2x / Zoom4x Toggles on/off the TapZoom functionality between different magnica-
tions of the video image: 2x (200%) or 4x (400%). This setting also
applies to zooming via use of the Control knob.
i If TapZoom is disabled, the label for this soft key button will be NoZoom.
Peak Toggles on/off the display of peaking lter focus assist tool.
Marker Toggles on/off the display of guide markers over the video image.
i Holding down most monitoring soft key buttons for more than a second will
open a menu related to that button’s functionality.
Record Soft Keys
When soft key buttons are set for alternate record functionality, the following
soft key labels appear and the buttons function as described:
LabeL Description
Display Hides or reveals OSD elements: soft key labels and/or the information bar.
Audio Displays the Audio screen. Track arm status, track name, input source, input
gain, and input delay can be viewed and adjusted for every track. Also dis-
plays metering for all tracks.
Files Accesses the Files screen, showing les recorded on the PIX-E5 as a list of
clips.
Stop Stops the recording or playback. When stopped, the label appears with a
yellow background and a yellow square icon appears on the information bar.
While stopped, pressing Stop reveals the next le name in the information
bar.
Play / Pause Starts playback. During playback, the label appears with a green background
and a green arrow icon appears on the information bar. The timecode, abso-
lute time, and le name also appear green.
Pressing the button during playback will pause playback. While paused, the
Pause soft key label ashes, and the Pause icon ashes on the information
bar.
