Overview of Printer Parts
The main parts of the Videojet DataFlex 6420 printer is described as
follows:
•CLARiTY
®
Controller: Houses the power supply unit and touch
screen. You can access jobs, setup jobs, set the various print
parameters using the touch screen
• Printer: Houses the printhead and ribbon. The data is transferred to
the printhead from the controller. The printhead prints onto the
packaging film.
1. CLARiTY
®
Controller Bracket
2. CLARiTY
®
Controller
3. Low Profile Cable Assembly
4. Air Regulator
5. 4-mm Air Tubing
6. Power Cable
7. CD
8. QA Documentation and CE Certificate
9. Cassette
10. Printer
Figure 2-2: Standard Printer Configuration Parts
