5-10 Checking and Replacing the Ribbon Rev AA
Videojet DataFlex 6420 Operator Manual
Replacing the Ribbon
EQUIPMENT DAMAGE. The use of incompatible ribbon can
seriously damage your printer and such damage will not be covered
by your printer warranty. Use only the ribbon that is approved by
your dealer.
To replace the ribbon, proceed as follows:
1 Remove the cassette.
2 Put the cassette down on a flat surface with the ribbon spools facing
upwards and the ribbon rollers towards you, as shown in Figure 5-10.
Figure 5-10: Cassette Removal
1
2
1. Ribbon Spool (x2)
2. Ribbon Roller (x2)
