3-12 Printing a Test Image Rev AA
Videojet DataFlex 6420 Operator Manual
6 Touch to select your region from the list (all the currently available
regions will be listed) and touch OK.
7 Touch the Language button. A list of available languages is displayed.
8 Touch to select your language from the list (all the currently available
languages will be listed) and touch OK.
9 Touch the Home button to return to the home page.
The date format displayed in the home page changes according to the
region selected.
Printing a Test Image
Typically, the printer is used on a packaging machine where the print is
triggered by a sensor or a Programmable Logic Controller (PLC).
A test image can be printed before running the printer to check if the
printed image is of acceptable quality. The Test Print button
(Figure 3-13), will appear greyed out if this feature has been disabled by
the installation engineer. Also, the printer must be set to RUNNING state
for the Test Print button to be available.
Figure 3-13: Test Print Button
Test Print
Button
