Rev AA Printer Dimensions 7-7
Videojet DataFlex 6420 Operator Manual
Printer Dimensions
Standard Models
Figure 7-1 shows the dimensions of the 53 mm (RH) printer.
Figure 7-1: Videojet DataFlex 6420 53 mm RH Printer Dimensions
204 mm
178 mm
70 mm Printhead Stoke
53 mm Printable Area
180 mm
(7.08 inches)
(8.03 inches)
(7. 0 inches)
