7-8 Printer Dimensions Rev AA
Videojet DataFlex 6420 Operator Manual
Figure 7-2 shows the dimensions of the 53 mm (LH) printer.
Figure 7-2: Videojet DataFlex 6420 53 mm LH Printer Dimensions
71 mm Printhead Stoke
204 mm
180 mm
178 mm
53 mm Printable Area
(8.03 inches)
(7.0 inches)
(7.08 inches)
