Rev AA Technical Specifications 7-1
7
Specifications
This chapter contains the following topics:
• Technical specifications
• System specifications
• Print specifications
• Networking and external communications
• Printer dimensions
Technical Specifications
Table 7-1 lists the technical specifications of the printer.
Technical
Specification
Videojet DataFlex 6420
53 mm
Videojet DataFlex 6420
107 mm
Printer
Unique
SolidState
Ribbon Drive
Intermittent Motion and
Continuous Motion
Intermittent Motion and
Continuous Motion
Printhead 53 mm (2.1”), 300 dpi, 12
dots/mm
107 mm (4.2”), 300 dpi,
12 dots/mm
Print Area -
Intermittent
Motion Mode
53 mm (W) x 75 mm (L)
(2.1” x 2.9”)
107 mm (W) x 75 mm (L)
(4.2” x 2.9”)
Print Area -
Continuous
Motion Mode
53 mm (W) x 200 mm (L)
(2.1” x 7.87”)
107 mm (W) x 200 mm
(L) (4.2” x 7.87”)
Ribbon Width 20 mm - 55 mm (0.8”-
2.2”)
55 mm - 110 mm (2.2” -
4.2”)
Maximum
Ribbon Length
1200 metres (3937’) 700 metres (2296’)
Table 7-1: Technical Specifications
