VIDEOJET DataFlex 6420 - Page 82

Rev AA Technical Specifications 7-3
Videojet DataFlex 6420 Operator Manual
External Outputs
(Fully software
configurable)
2 relay outputs (1
change-over + 1 N/O)
and 2 PNP +24V outputs
(max source current =
100mA per output),
configurable from
CLARiTY
®
Configuration
Manager
On-line/Off-line
Warning
Busy
Printing (actually
energising print dots)
Labeller feed
Print cycle active (Start to
end of print and ribbon
rewind)
Update print queue full
New allocation
Print failed (i.e.
interrupted in mid print)
Fault
2 relay outputs (1
change-over + 1 N/O)
and 2 PNP +24V outputs
(max source current =
100mA per output),
configurable from
CLARiTY
®
Configuration
Manager
On-line/Off-line
Warning
Busy
Printing (actually
energising print dots)
Labeller feed
Print cycle active (Start to
end of print and ribbon re-
wind)
Update print queue full
New allocation
Print failed (i.e.
interrupted in mid print)
Fault
Operator
Interface
(CLARiTY
®
)
8.4” TFT SVGA 8.4” TFT SVGA
Power supply
requirements
100 -240 VAC, 50/60 Hz,
3.2-1.3 A
100 -240 VAC, 50/60 Hz,
3.2-1.3 A
Air supply
requirements
6 bar, 90 psi,
uncontaminated, 1.0 ml/
cycle (max)
6 bar, 90 psi,
uncontaminated, 1.0 ml/
cycle (max)
Operating
Temperature
5° - 40° C (41° - 104° F) 5°- 40° C (41° - 104° F)
1. Print speeds and throughput are resolution, substrate, application
and set-up dependent.
Technical
Specification
Videojet DataFlex 6420
53 mm
Videojet DataFlex 6420
107 mm
Table 7-1: Technical Specifications (Continued)
