ViewZ VZ-IP-PVM-N Series User Manual

33User Manual Visit the ViewZ USA website at https://www.viewzusa.com
6. Configuration of Analog Output (CVBS)
CONFIGURATION / DEVICE
Preparation
Description
Procedure
Connect a display device to the VIDEO OUT port.
When the analog output funcon is enabled, the IP camera can send analog signals to a video server or display
device through the VIDEO OUT port.
Step 1 Choose Device Conguraon > Device > CVBS
The BNC Video Output page is displayed, as shown in Figure 5-6.
Step 2 Click the buon on to enable BNC Video Output.
Step 3 Click Apply. The message "Apply success!" is displayed.
Step 4 Click Conrm. The system saves the sengs.
Figure 5-6 BNC config page
