Page #30 background imageLoading...
Page #30 background image
30 User ManualVisit the ViewZ USA website at https://www.viewzusa.com
5. Setup OSD Parameters
CONFIGURATION / DEVICE
Description
Procedure
The on-screen display (OSD) funcon allows you to display the device name, channel ID and name, me, and
other customized content on videos.
When the resoluon is D1 and CIF, the maximum number of words that can be displayed is 22 words
The OSD supports English, digital and some special characters only.
The size of characters that can be displayed in a row or column varies according to the resoluon. When the
OSD font is auto:
If the resoluon is 1920 x 1080 and the size of each character is 48 x 48, then the maximum row of OSD is
22 (1080/48), and the maximum column is 40 (1920/48);
If the resoluon is 704 x 576 and the size of each character is 32 x 32, then the maximum row of OSD is 18
(576/32), and the maximum column is 22 (704/32);
If the resoluon is 640 x 360 and the size of each character is 16 x 16, the maximum row of OSD is
22(360/16) characters, and a maximum column is 40(640/16).
Step 1 Choose Device Conguraon > Device > OSD.
The OSD page is displayed, as shown in Figure 5-5.
Step 2 Set the parameters according to Table 5-5.
Figure 5-5 OSD page
