Gate control via SW/HW gate, canceling (HW gate activated, gate
function: Cancel count)
SW gate HW gate Reaction Counter
edge 0-1 1 Continue
1 edge 0-1 Restart with load
value
Gate control via SW/HW gate, stopping (HW gate activated, gate
function: Stop count)
SW gate HW gate Reaction Counter
edge 0-1 1 Continue
1 edge 0-1 Continue
Gate control via SW/HW gate, operating mode "Count once" If the
internal gate has been closed automatically it may only be opened
again under the following conditions:
SW gate HW gate Reaction I gate
1 edge 0-1 1
edge 0-1
(nach edge 0-1
am HW-Tor)
edge 0-1 1
As soon as during a count process an edge 0-1 is recognized at the
"Latch" input of a counter, the recent counter value is stored in the
according latch register. The latch value may be accessed by the
parameter LATCHVAL of the SFB 47. A just in LATCHVAL loaded
value remains after a STOP-RUN transition.
In the CPU a comparison value may be stored that is assigned to the
digital output, to the status bit "Status Comparator" STS_CMP and to
the hardware interrupt. The digital output may be activated depending
on the count value and comparison value. A comparison value may
be entered by the parameter assignment screen form respectively by
the request interface of the SFB 47.
Gate control "Count
once"
Latch function
Comparator
VIPA System 300SDeployment I/O periphery
Counter > Counter - Additional functions
HB140 | CPU-SC | 313-6CF13 | GB | 15-50 122
