The record set 1 contains the 4byte of the record set 0 and addition-
ally 12byte module specific diagnostic data. The diagnostic bytes
have the following assignment:
Byte Bit 7...0
0 ... 3
Content record set 0
Ä
‘Record set 0 Diagnostic
incoming
on page 142
4
n Bit 6 ... 0: Channel type (here 70h)
70h: Digital input
71h: Analog input
72h: Digital output
73h: Analog output
74h: Analog input/output
n Bit 7: More channel types present
0: no
1: yes
5 Number of diagnostic bits per channel (here 08h)
6 Number of channels of a module (here 08h)
7
n Bit 0: Error in channel group 0 (I+0.0 ... I+0.3)
n Bit 1: Error in channel group 1 (I+0.4 ... I+0.7)
n Bit 2: Error in channel group 2 (I+1.0 ... I+1.3)
n Bit 3: Error in channel group 2 (I+1.4 ... I+1.7)
n Bit 4: Error in channel group 4 (counter 0)
n Bit 5: Error in channel group 5 (counter 1)
n Bit 6: Error in channel group 6 (counter 2)
n Bit 7: reserved
8 Diagnostic interrupt due to "process interrupt lost" at...
n Bit 0: ... input I+0.0
n Bit 1: 0 (fix)
n Bit 2: ... input I+0.1
n Bit 3: 0 (fix)
n Bit 4: ... input I+0.2
n Bit 5: 0 (fix)
n Bit 6: ... input I+0.3
n Bit 7: 0 (fix)
9 Diagnostic interrupt due to "process interrupt lost" at...
n Bit 0: ... input I+0.4
n Bit 1: 0 (fix)
n Bit 2: ... input I+0.5
n Bit 3: 0 (fix)
n Bit 4: ... input I+0.6
n Bit 5: 0 (fix)
n Bit 6: ... input I+0.7
n Bit 7: 0 (fix)
Diagnostic record set 1
at counter function
VIPA System 300S Deployment I/O periphery
Diagnostic and interrupt > Diagnostic interrupt
HB140 | CPU-SC | 313-6CF13 | GB | 15-50 143
