Byte Bit 7...0
10 Diagnostic interrupt due to "process interrupt lost" at...
n Bit 0: ... input I+1.0
n Bit 1: 0 (fix)
n Bit 2: ... input I+1.1
n Bit 3: 0 (fix)
n Bit 4: ... input I+1.2
n Bit 5: 0 (fix)
n Bit 6: ... input I+1.3
n Bit 7: 0 (fix)
11 Diagnostic interrupt due to "process interrupt lost" at...
n Bit 0: ... input I+1.4
n Bit 1: 0 (fix)
n Bit 2: ... input I+1.5
n Bit 3: 0 (fix)
n Bit 4: ... input I+1.6
n Bit 5: 0 (fix)
n Bit 6: ... input I+1.7
n Bit 7: 0 (fix)
12 Diagnostic interrupt due to "process interrupt lost" at...
n Bit 0: ... gate counter 0 closed
n Bit 1: 0 (fix)
n Bit 2: ... gate counter 0 opened
n Bit 3: 0 (fix)
n Bit 4: ... over-/underflow/end value counter 0
n Bit 5: 0 (fix)
n Bit 6: ... counter 0 reached comparison value
n Bit 7: 0 (fix)
13 Diagnostic interrupt due to "process interrupt lost" at...
n Bit 0: ... gate counter 1 closed
n Bit 1: 0 (fix)
n Bit 2: ... gate counter 1 opened
n Bit 3: 0 (fix)
n Bit 4: ... over-/underflow/end value counter 1
n Bit 5: 0 (fix)
n Bit 6: ... counter 1 reached comparison value
n Bit 7: 0 (fix)
14 Diagnostic interrupt due to "process interrupt lost" at...
n Bit 0: ... gate counter 2 closed
n Bit 1: 0 (fix)
n Bit 2: ... gate counter 2 opened
n Bit 3: 0 (fix)
n Bit 4: ... over-/underflow/end value counter 2
n Bit 5: 0 (fix)
n Bit 6: ... counter 2 reached comparison value
n Bit 7: 0 (fix)
15 reserved
VIPA System 300SDeployment I/O periphery
Diagnostic and interrupt > Diagnostic interrupt
HB140 | CPU-SC | 313-6CF13 | GB | 15-50 144
