Order no. 313-6CF13
Destruction limit against external applied
voltage
-
Settling time for ohmic load -
Settling time for capacitive load -
Settling time for inductive load -
Resolution in bit -
Conversion time -
Substitute value can be applied -
Output data size -
Technical data counters
Number of counters 3
Counter width 32 Bit
Maximum input frequency 30 kHz
Maximum count frequency 30 kHz
Mode incremental encoder
ü
Mode pulse / direction
ü
Mode pulse
ü
Mode frequency counter
ü
Mode period measurement
ü
Gate input available
ü
Latch input available
ü
Reset input available -
Counter output available
ü
Load and working memory
Load memory, integrated 512 KB
Load memory, maximum 512 KB
Work memory, integrated 128 KB
Work memory, maximal 512 KB
Memory divided in 50% program / 50% data
ü
Memory card slot MMC-Card with max. 1 GB
Hardware configuration
Racks, max. 4
Modules per rack, max. 8
Number of integrated DP master 1
Number of DP master via CP 4
Operable function modules 8
