Order no. 313-6CF13
Operable communication modules PtP 8
Operable communication modules LAN 8
Status information, alarms, diagnostics
Status display yes
Interrupts yes
Process alarm yes
Diagnostic interrupt yes
Diagnostic functions no
Diagnostics information read-out possible
Supply voltage display green LED
Group error display red SF LED
Channel error display red LED per group
Isolation
Between channels
ü
Between channels of groups to 16
Between channels and backplane bus
ü
Between channels and power supply -
Max. potential difference between circuits DC 75 V/ AC 50 V
Max. potential difference between inputs (Ucm) -
Max. potential difference between Mana and
Mintern (Uiso)
-
Max. potential difference between inputs and
Mana (Ucm)
-
Max. potential difference between inputs and
Mintern (Uiso)
-
Max. potential difference between Mintern and
outputs
-
Insulation tested with DC 500 V
Command processing times
Bit instructions, min. 0.02 µs
Word instruction, min. 0.02 µs
Double integer arithmetic, min. 0.02 µs
Floating-point arithmetic, min. 0.12 µs
Timers/Counters and their retentive charac-
teristics
Number of S7 counters 512
Number of S7 times 512
Data range and retentive characteristic
VIPA System 300S Hardware description
Technical data
HB140 | CPU-SC | 313-6CF13 | GB | 15-50 41
