Event-ID Description
0xE400 Memory card with the option memory expansion was plugged
0xE401 Memory card with the option memory expansion was removed
0xE402 The PROFIBUS DP master functionality is disabled. The interface acts fur-
ther as MPI interface
0xE403 The PROFIBUS DP slave functionality is disabled. The interface acts further
as MPI interface
0xE500 Memory management: Deleted block without corresponding entry in Block
List
ZInfo2: BlockType
ZInfo3: BlockNo
0xE604 Multiple parametrization of a periphery address for Ethernet PG/OP channel
ZInfo1: Periphery address
ZInfo3:
0: Periphery address is input, 1: Periphery address is output
0xE701 Internal error - Please contact the VIPA Hotline!
0xE703 Internal error - Please contact the VIPA Hotline!
0xE720 Internal error - Please contact the VIPA Hotline!
0xE721 Internal error - Please contact the VIPA Hotline!
0xE801 CMD - Auto command: CMD_START recognized and successfully executed
0xE802 CMD - Auto command: CMD_End recognized and successfully executed
0xE803 CMD - Auto command: WAIT1SECOND recognized and successfully exe-
cuted
0xE804 CMD - Auto command: WEBPAGE recognized and successfully executed
0xE805 CMD - Auto command: LOAD_PROJECT recognized and successfully exe-
cuted
0xE806 CMD - Auto command: SAVE_PROJECT
Zinfo3: 0x0000: SAVE_PROJECT recognized and successfully executed
Zinfo3: 0x8000: Error during SAVE_PROJECT e.g. wrong password
0xE807 CMD - Auto command: FACTORY_RESET recognized and successfully
executed
0xE80B CMD - Auto command: DIAGBUFF recognized and successfully executed
0xE80E CMD - Auto command: SET_NETWORK recognized and successfully exe-
cuted
0xE816 CMD - Auto command: SAVE_PROJECT: Error - CPU has been reset - no
wld file was created.
VIPA System 300SDeployment CPU 313-6CF13
VIPA specific diagnostic entries
HB140 | CPU-SC | 313-6CF13 | GB | 15-50 82
