Event-ID Description
0xEA6F PROFINET IO controller
PN module mismatch
PK: Rackslot
OBNo: PLC-Mode
DatId: 0
ZInfo1: Device ID
ZInfo2: -
ZInfo3: -
0xEA97 Storage error SBUS service channel
ZInfo3 = Slot
0xEA98 Timeout at waiting for reboot of a SBUS module (server)
0xEA99 Error at file reading via SBUS
0xEAA0 Emac Error occurred
OBNo: Current PLC mode
ZInfo1: Diagnostics address of the master / controller
ZInfo2:
0: None Rx queue is full
1: No send buffer available
2: Send stream was cut off; sending failed
3: Exhausted retries
4: No receive buffer available in Emac DMA
5: Emac DMA transfer aborted
6: Queue overflow
7: Unexpected frame received
ZInfo3: Number of errors, which occurred
0xEAB0 Link mode not valid
OBNo: Current PLC mode
ZInfo1: Diagnostics address master / controller
Zinfo2: Current LinkMode
0x01: 10Mbit full-duplex
0x02: 100Mbit half-duplex
0x03: 100Mbit full-duplex
0x05: 10Mbit half-duplex
0xFF: Link mode not defined
0xEB03 SLIO error on IO mapping
0xEB10 SLIO error: Bus error
ZInfo1: Type of error
0x82: ErrorAlarm
VIPA System 300SDeployment CPU 313-6CF13
VIPA specific diagnostic entries
