Event-ID Description
0xEB20 SLIO error: Interrupt information undefined
0xEB21 SLIO error on accessing the configuration data
0xEC03 EtherCAT: Configuration error
ZInfo1: Errorcode
1: NUMBER_OF_SLAVES_NOT_SUPPORTED
2: SYSTEM_IO_NR_INVALID
3: INDEX_FROM_SLOT_ERROR
4: MASTER_CONFIG_INVALID
5: MASTER_TYPE_ERROR
6: SLAVE_DIAG_ADDR_INVALID
7: SLAVE_ADDR_INVALID
8: SLAVE_MODULE_IO_CONFIG_INVALID
9: LOG_ADDR_ALREADY_IN_USE
10: NULL_PTR_CHECK_ERROR
11: IO_MAPPING_ERROR
12: ERROR
0xEC04 EtherCAT: Multiple configuration of a periphery address
ZInfo1: Periphery address
ZInfo2: Slot
0xEC10 EtherCAT: Restoration bus with its slaves
OB start Info (Local data) StartEvent and Eventclass: 0xEC10
DatID:
0xXXYY:
XX=0x54 with input address in ZInfo1,
XX=0x55 with output address.
YY=0x00 Station not available,
YY=0x01 Station available (process data)
ZInfo1: 0xXXYY (XX=OldState, YY=NewState)
ZInfo2: Diagnostics address of the master
ZInfo3: Number of stations, which are not in the same state as the master
(> 0)
VIPA System 300S Deployment CPU 313-6CF13
VIPA specific diagnostic entries
