Visonic KP-250 PG2 Installer's Guide

3. Programming
3.1 General Guidance
This chapter explains the Installer programming (configuration) options of your KP-250 PG2 device and how to
customize its operation to your particular needs end user requirements.
The alarm system includes a partition feature. Partitioning allows you to have up to three independently controllable
areas with different user codes assigned to each partition. A partition can be armed or disarmed regardless of the status
of the other partitions within the system.
The Soak Test feature allows selected zones to be tested for a pre-defined period of time. When in Soak Test mode,
activating a zone does not cause an alarm, and siren and strobe are not activated. The zone activation is recorded in the
event log and is not reported to the Monitoring Station. The zone remains in Soak Test until the pre-defined period of time for
the Soak Test has elapsed without any alarm activation. The zone then automatically removes itself from Soak Test mode.
Software Upgrade allows you to upgrade the software of the control panel from the remote PowerManage server.
During software upgrade, the PowerMaster display will read "UPGRADING…" which is displayed throughout the
software upgrade procedure.
Note: Software Upgrade cannot be performed when the control panel is armed AWAY, there is an AC failure, one of the
enrolled KPs is not communicating to the panel for some reason, or one of the enrolled KPs is in low battery state.
3.1.1 Navigation
The keypad's buttons are used for various functions when programming. The following table provides a detailed
description of the function or use of each button.
Button
Definition
Navigation / Setting Function
NEXT
Use to move / scroll forward to the next menu options.
BACK
Use to move / scroll backward to the previous menu options.
OK
Use to select a menu option or to confirm a setting or action.
Escape
Use to move one level up in the menu or to return to previous
setting step.
Delete / abort
Use to edit a field or jump back to the [<OK> TO EXIT] screen to quit
programming.
-
Numerical keypad used to enter alphanumerical data.
Partition selection
Use to change the status of partitions when programming user codes
3.1.2 Feedback Sounds
The sounds you will hear while using and configuring the keypad are:
Sound
Definition
Single beep, heard whenever a key is pressed
Double beep, indicates automatic return to the normal operating mode (by timeout).
Three beeps, indicates a trouble event
♫
Success Tune (- - - –––), indicates successful completion of an operation.
♫

Failure Tune
(–––––), indicates a wrong move or rejection
You can control the volume level of the sounded beeps by pressing the button on the keypad to increase the
volume of the beeps heard, or by pressing the button to decrease the volume of the beeps heard.
D-306919 KP-250 PG2 Installer’s Guide 9
