Vitrek 952i - Page 131

95x Series Operating Manual - May 17, 2022
Page 131 of 155
Command
Description
MEASRSLT?,<STRING>
Responds with a <NR3> measurement result during execution of a test
step. <STRING> is –
FREQ – frequency (in Hz)
AMPS – DC or RMS current (in Amps)
INPHSA – In-phase current (in Amps)
QUADA – quadrature current (in Amps)
VOLTS – DC or RMS voltage (in Volts)
INPHSV – In-phase voltage (in Volts)
QUADV – quadrature voltage (in Volts)
OHMS – DC or RMS impedance (in Ω)
INPHSO – In-phase impedance (in Ω)
QUADO – quadrature impedance (in Ω)
ARC – arc current (in Amps)
ARCC – arc counter in counts
BRKDN – breakdown current (in Amps)
CAP – capacitance (in F)
DF – dissipation factor (unitless)
Test Result Query Commands
(After running a test sequence)
RSLT?
Responds with a <NR1> indicating the overall test sequence fail status
and reason. This is the logical OR of all individual step status flags. This
can also be used while running a test sequence.
See
Test Step Status Flags
STAT?
Responds with a <STRING> indicating the pass/fail state of each test step.
This can also be used while running a test sequence. The response
contains one character for each defined test step-
P passed
F failed
- Not performed
? In process
STEPRSLT?,<NR1>
Responds with a set of fields giving the complete set of results for the
specified test step. See
STEPRSLT? Response Fields
ARCCRSLT?,<NR1>
Responds with an NR1 carrying the arc count for the specified test step.
Configuration Settings Commands
BEEP,START,<NR1>
Configures the start beep sounds to 0 (off) to 4 (loud)
BEEP?,START
Responds with the <NR1> setting of the start beep sound
BEEP,PASS,<NR1>
Configures the pass beep sounds to 0 (off) to 4 (loud)
BEEP?,PASS
Responds with the <NR1> setting of the pass beep sound
BEEP,FAIL,<NR1>
Configures the fail beep sounds to 0 (off) to 4 (loud)
BEEP?,FAIL
Responds with the <NR1> setting of the fail beep sound
BEEP,KEY,<NR1>
Configures the key press beep sounds to 0 (off) to 4 (loud
BEEP?,KEY
Responds with the <NR1> setting of the key press beep sound
CONTSENSE,<BOOL>
Configures the Continuity Sense feature
CONTSENSE?
Responds with the <BOOL> Continuity Sense feature setting
DATE,<NR1>,<NR1>,<NR1>
Sets the present date (month, date, year)
DHCP,<BOOL>
Configures the Ethernet DHCP setting
DHCP?
Responds with the <BOOL> Ethernet DHCP setting
DIO,START,<STRING>
Configures the START DIO input to OFF, HI or LO
