110ENGINECOMPONENTANDLOCATION

CoolingSystem

Thecoolingsystemincorporatesabelt-drivencoolantpumpmountedonthefrontof

theengineontheright.Italsousesapiston-typethermostathousedinthefrontof

thecylinderheadandafanwithviscousorair-operateddrivemountedabovethe

crankshaftpulley.Acoolantconditioner(lter)attachedtothepumphousinglters

impuritiesfromthecoolantandreleasessupplementalcoolantadditivesforsystem

protection.

CoolantPump

W2033363

1.ImpellerHousing3.CoolantPumpMountingPlate

2.CoolantPumpSeal

Thebackofthecoolant(water)pump,withitsductsfordistributingcoolant,isa

separatecastingattachedtothecylinderblock.

Ahousingcontaininganimpeller,shaftseals,bearingandpulleyattachestothe

mountingplate.Thebearingisapermanentlylubricatedcombinationrollerandball

bearing.Betweentheshaftsealsandthebearing,thereisaventilatedspacewhich

leadsintoaductbehindthepulley.Thisallowsinternalleakstobedetected.
