68SPECIFICATIONS

ValveGuides

Length

Inlet/Exhaust

83.5mm(3.287inches)

Innerdiameter

Inlet/Exhaust

8mm(0.315inch)

Heightabovecylinderheadspringsurface

Inlet/Exhaust

24.5±0.2mm(0.965±0.008inch)

ValveSprings

Inletvalvespring

Lengthunloaded

73.8mm(2.91inches)

Exhaustoutervalvespring

Lengthunloaded

73.8mm(2.91inches)

Exhaustinnervalvespring

Lengthunloaded

70.5mm(2.78inches)
