Volvo EPA2007 D13F - Exhaust Aftertreatment System Maintenance; Diesel Particulate Filter; Compact Unit

BASICSERVICE143
ExhaustAftertreatmentSystemMaintenance
DieselParticulateFilter
Thedieselparticulateltershouldberemovedfromthesystemandreplacedatthe
recommendedserviceinterval.Ifthelterisnotreplaced,itwillbecomeclogged
andincreaseexhaustbackpressure.Asbackpressureincreases,enginepowerand
economydeclineasdoestheabilityofthesystemtoremoveundesirableemissions.
CompactUnit
WARNING
Thecomponentsreachhightemperaturesduringuse.Ensurethattheunithas
cooledtothetouchbeforehandling.Failuretoheedthiswarningmayresultin
severepersonalinjury.
Removal
1.Whenthefairing(ifpresent),bracesandstepshavebeenremovedtopermitaccess,
removethelinesandsensorsconnectingtheinletmoduletotheothermodules.
2.DisconnectwiringandsensorconnectorsfromtheDPFandoutletmodules.Cut
tiestrapssecuringthelowerportionoftheDPFharnesstothemuferbody.Also,
removethepressuredifferentialsensortubethatconnectstotheoutletmodule.
W2033378
3.Usingamarker,makealignmentmarksoneachofthemodulesections,above
andbeloweachV-bandclamp.
