ENGINECOMPONENTANDLOCATION83

CylinderLiner

W2033311

1.UpperO-Ring–EPDM(Black)3.LowerSealingRing–Viton(Purple)

2.MiddleSealingRings–EPDM(Black)

Thecylinderblockusesreplaceablewetcylindersleeves.Thelowerendofeachsleeve

issealedagainsttheblockwiththreeelastomerrings.Theupperendissealedwitha

ringofEPDMelastomersituateddirectlyunderthesleevecollar.Thisdesigncools

theuppersectionofthesleevebetterbecausetheareaofcoolantcirculationislarger.

Thelowersealsarettedingroovesinthecylinderblock.Thebottomsealisofa

differentmaterialanduorescentvioletincolortodistinguishitfromtheintermediate

seals.
