84ENGINECOMPONENTANDLOCATION

OilPan

W2033312

1.BlockStiffenerPlate2.OilPanwithGasket

Theoilpanisplasticorsteelwithathreadedplugfordraining.Theplasticpanhasa

grooveinthemountingangewhichacceptsamoldedelastomergasketforaseal.

Thesteelpanissealedwithagasketontheoilpanange.Twenty-twospring-loaded

screwsclampthepantotheblock.

Theoilpanincludesanoillevel/temperaturesensorwithconnector.Thellertube

anddipstickmountingportsarealsocomponentsoftheoilpan.

Note:Oilpanswiththesumpatthefrontorattherearareavailabletoaccommodate

axleforwardoraxlebackchassis.
