Volvo EPA2007 D13F - Camshaft and Valve Train

SPECIFICATIONS71
CamshaftBearings
Camshaftbearingthickness,standard1.92mm(0.075inch)
Oversize
0.25mm(0.010inch)2.04mm(0.080inch)
0.50mm(0.020inch)2.17mm(0.085inch)
0.75mm(0.030inch)2.29mm(0.090inch)
CrankMechanismMainBearingJournals
Standarddiameter(Ø)108.0mm(4.25inches)
Undersizediameter
0.25mm(0.010inch)107.75mm(4.2421inches)
0.50mm(0.020inch)107.50mm(4.2323inches)
0.75mm(0.030inch)107.25mm(4.2224inches)
1.00mm(0.040inch)107.00mm(4.2126inches)
1.25mm(0.050inch)106.75mm(4.2027inches)
Surfacenish,mainbearingjournal
Ra0.25
Surfacenish,radius
Ra0.4
Width,axialbearingpin(A),standard47.0mm(1.850inches)
Oversize
0.2mm(0.008inch),axialbearing
0.1mm(0.004inch)
47.2mm(1.858inches)
0.4mm(0.016inch),axialbearing
0.2mm(0.008inch)
47.4mm(1.866inches)
0.6mm(0.241inch),axialbearing
0.3mm(0.012inch)
47.6mm(1.874inches)
Recessradius(R)4.0mm(0.157inch)
