ENGINECOMPONENTANDLOCATION81

HeadtoBlockAlignment

W2033310

1.CylinderHead3.CylinderClock

2.AlignmentScrewsandWashers

Threescrewsandwashersinstalledattheside(twointheblockandoneinthehead)

aligntheheadfromsidetosideatassembly.Foreandaft,theheadisalignedby

contactwiththetiminggearplate.

CAUTION

Theheadisalignedwiththetiminggearplatebyscrewspassedthroughtheplate

intotheheadandtightenedsecurely.Itisextremelyimportanttoremovethese

screwsbeforeattemptingtoremovethecylinderheadfromtheblock.Failureto

heedthiscautionmayresultinseveredamagetothetiminggearplateandother

enginecomponents.
