Volvo EPA2007 D13F - Timing Gears

88ENGINECOMPONENTANDLOCATION
TimingGears
W2033318
1.CrankshaftGear6.PowerSteering/FuelPumpGear
2.DoubleIdlerGear7.AirCompressorGear
3.AdjustableIdlerGear
8.OilPumpGear
4.CamshaftGearandDamper9.PowerTake-OffGear(Optional)
5.AuxiliaryIdlerGear10.TimingGearPlate
Thetiminggearsarelocatedattherearoftheengine.Backingupthegearsisaplate:
a6mm(1/4inch)thicksteelsheetattachedtothecylinderblock.
Theadvantagesofthiscongurationaremoreprecisetiming,fewercomponents
andlowernoiselevels.
Thepowersteering/fuelpumpgear,theaircompressorgearandthePTOgeararenot
timinggears.Thepumpandcompressorgearsfastentotheirrespectivecomponents.
Thepumpgearisdrivenbytheauxiliaryidlergear.Thecompressorgearisdriven
bythedoubleidlergear.
Thedoubleidlerdrivestheadjustableidlerandthegearusedtodrivethepower
take-off,ifsoequipped.Thisispartofthe"REPTO-Ready"feature.APTOunitwith
drivegearissubstitutedforacoverontheywheelhousing.
Thecamshaftgearfastenstothehubontheendoftheshaft.Avibrationdamperalso
attachestothehuboutboardofthegear.Teethonthedamperactuatethecamshaft
positionsensor.Thegearisdrivenviatheadjustableidler.
