Volvo EPA2007 D13F - Page 172

166BASICSERVICE
W2033402
A.Locknut
B.AdjustingScrew
a.LoosenthelocknutAonthebrakerockerarmadjustingscrew.
b.Usingthedialindicatorwithangledextensionandbase(9989876,85111493and
9999696),placethetipofthedialgaugeontheyokeascloseaspossibletotherocker
armyokepad.Zerothegauge.
c.TightentherockerarmadjustingscrewBuntilthedialshowsthattheyokehas
beenpusheddownward0.60±0.05mm(0.024±0.002inch).
d.Loosentherockerarmadjustingscrewtwofullturns(720°).
e.Holdtheadjustingscrewtopreventitfromturningfurtherand,usingatorque
wrench,tightenthelocknuttospecication
6.Removethedialindicatorandthefeelergauge.
