SPECIFICATIONS21
TimingGears
W2006478
1.Drivegear,crankshaft...........................................................24±4Nm(18±3ft-lb)
2.Doubleidlergear:
Step1........................................................................................25±3Nm(19±2ft-lb)
Step2(angletightening)........................................................................110±5degrees
Note:Tightenfollowingtheordershownintheillustration.
3.Idlergear,adjustable:
Step1........................................................................................35±4Nm(26±3ft-lb)
Step2(angletightening)........................................................................120±5degrees
Note:Tightenfollowingtheordershownintheillustration.
4.Drivegear,camshaft(includesvibrationdamper):
Step1........................................................................................45±5Nm(33±4ft-lb)
Step2(angletightening)..........................................................................90±5degrees
Note:Tightenfollowingtheordershownintheillustration.
5.Idlergear:140±10Nm(103±7ft-lb)
6.Drivegear,powersteeringpump:100±10Nm(74±7ft-lb)
7.Drivegear,aircompressor:200+50-0Nm(147+37-0ft-lb)
