32SPECIFICATIONS

Locknut,V olvoEngineBrakeRockerArm

W2005946

Locknut,V olvoEngineBrakerockerarm................................52±4Nm(38±3ft-lb)

or,angletightenaftercontact...................................................................45±5degrees
