Volvo EPA2007 D13F - Page 43

SPECIFICATIONS37
Oilcooler,retainingbolts
T2022733
Step1.........................................................................................5±1Nm(44±9in-lb)
Step2........................................................................................27±4Nm(20±3ft-lb)
Note:Tightentheboltsdiagonallyandnishbytighteningtherstboltagain.
Oilcoolercover
T2023837
Positionthecovertotheengineblockandinstallbolt(A)intotheovalhole.Pressthe
coveragainstthewaterpumphousingusinganassemblytool88800022andinstall
bolt(B).Checkthatthecoverispositionedcorrectly.
InstallboltsCandDandtighten..............................................24±4Nm(18±3ft-lb)
Tightenthecoverboltsfromthemiddleandoutwardsinorder1–4asshown....24±4
Nm(18±3ft-lb)
FinishbycheckingthetorqueforboltsCandD......................24±4Nm(18±3ft-lb)
