42SPECIFICATIONS

AftertreatmentFuelSupplyLine

W2005926

1.AftertreatmentFuelInjector,fuel

supplyline

15±0.5Nm(135±5in-lb)

2.MountingBolts14Nm(125in-lb)

3.Two-WayCheckV alve15Nm(135in-lb)

4.AirLine27Nm(235in-lb)
