Volvo EPA2007 D13F

To Next Page

To Previous Page

SPECIFICATIONS49

W2005481

BoltHeadPunchMarks

CAUTION

Boltsforthefollowingcomponentsmaybereusedfourtimesonly.Theheadsof

theseboltsmustbemarkedwithapunch(A)aftereachuse.Whenre-usingbolts,

theboltheadandthreadsmustbelubricatedwithcleanengineoil.Donotlubricate

newboltsastheyarealreadylubricated.

•CYLINDERHEADBOLTS

•CAMSHAFTandROCKERSHAFTBOLTS

•FLYWHEELBOLTS

•MAINBEARINGBOLTS

•CONNECTINGRODBOLTS

CAUTION

Donotre-usetiminggearmountingplatebolts.Donotre-usetiminggear

mountingbolts.Donotre-usepistonspraynozzlebolts
