78ENGINECOMPONENTANDLOCATION

W2033303

1.ExhaustBrakeCam

3.InjectorCam

2.ExhaustCam4.InletCam

Rollersintheendsoftherockerarmscontactthecamshaft.Thecontactswiththe

yokeshaveballsocketsforexibility.

Thecamshaftisinduction-hardened.Timingmarksforvalveandinjectoradjustment

arelocatedontheangeforwardoftheNo.1camshaftjournal.Thesemarksarefor

adjustingvalveclearance.Theydonotapplytocamshafttiming.

CamshaftthrustwashersareintegralontheNo.7journalbearing.Smoothrotationis

ensuredbymeansofavibrationdamperonthecamshaftgear.Teethonthedamper

interactwiththecamshaftpositionsensorforinputtotheEECU.
