BA RC50_RC70 en 00
183
[3] Battery isolation switch
Component Fuse assignment Fuse
F06 Battery disconnection switch 1 A
5.03.02 Electrical box
[4] Central electrical system
Component Fuse assignment Fuse
F1 Rear working spotlights 15 A
F2 Front working spotlights 15 A
F3 EGR valve, throttle flap 5 A
F4 Sensors at the diesel engine 5 A
F5 Left driving light 10 A
F6 Right driving light 10 A
F7 HCN, GPS (terminal 30) 5 A
F8 Cab (terminal 30) 10 A
F9 Diesel engine control unit (terminal 30) 20 A
F10 Ignition (start) switch (terminal 30), dashboard 15 A
F11 not used (terminal 30) 10 A
F12 not used (terminal 30) 10 A
F13 Rotating beacon 10 A
F14 High beam 15 A
F15 Cab heating 10 A
F16 Reversing alarm, reversing light 10 A
F17 not used (terminal 15) 10 A
F18 Dozer blade 10 A
F19 not used (terminal 15) 10 A
F20 not used (terminal 15, engine compartment) 10 A
F21 Display (terminal 15) 20 A
F22 Socket for on-board power supply (driver's platform) 15 A
F23 Sensors 5 A
F24 Signal horn 10 A
F25 not used (terminal 15, operator's seat console) 10 A
F26 EMERGENCY STOP, diesel engine control unit 5 A
F27 Compaction meter HCM 10 A
F28 Cab (terminal 15) 60 A
FC1 Plug-in socket for fuse test
NOTE
You can use the fusible test receptacle to check a fuse.
The green light-emitted diode (LED) lights up when the fuse is functional.
