Description
General view of machine
40
BA RC50_RC70 en 00
2.01.04 FOPS
21
12
11
6
48 9 10 4
4
7 35
[1] ROPS roll-over bar [2] ROPS roll-over bar type plate
[3] Protective roof with integrated FOPS [4] Handrails
[5] Working mirror/rear-view mirror [6] Headlight/turn signal
[7] Working spotlight [8] Seat console
[9] Storage compartment for operating manual/first
aid kit
[10] 12 V socket
[11] Steering column [12] Position for fire extinguisher
2.01.05 Cab
21
11
10
5
37 8 9 3
3
64
[1] ROPS cab [2] ROPS roll-over bar type plate
[4] Handrails [4] Working mirror/rear-view mirror
[5] Headlight/turn signal [6] Working spotlight
[7] Seat console [8] Storage compartment for operating manual/first
aid kit
[9] 12 V socket [10] Steering column
[11] Position for fire extinguisher
