Auxiliary equipment
Tachograph
196
BA RC50_RC70 en 00
Vibrator speed
The frequency of rotation [4] for the vibrator is recorded by the
tachograph on the rear of the record sheet. The recording shows the
revolutions per minute. The device also logs the switching on of the
electrical system (electrical system ON/OFF) [5].
Vibration amplitude
The area [3] under the driving speed [2] is used to record the amplitude
of the vibrations. A thick bar indicate a large amplitude, a thin bar a
small amplitude. On machines with double vibration, the recording of
the front drum is given priority. If the machine works with mixed vibration
amplitudes, that is one drum works with a large and the other with a small
amplitude, only the large amplitude is shown on the record sheet.
6.04.03 Operation
The operation of the trip recorder is described in the manufacturer's
instruction manual. This corresponds to the version current when the
machine is delivered.
