Operation
Adjusting the steering column
BA RC50_RC70 en 00
75
3.08 Adjusting the steering column
WARNING
Uncontrolled motion!
Injuries due to uncontrolled movements when changing the steering
column position when driving.
■
Only drive with latched unit of control panel with steering wheel.
■
Do not adjust the steering column when the machine is driving.
■
Free access to bodywork and engine parts.
The steering column can adapted to suit the driver.
The angle between the control panel unit and the steering wheel is
adjustable. This enables an ergonomic operating position to be achieved.
Ergonomic adjustment
Press foot lever [2].
The control panel with steering wheel unit [1] is swiwelled forward/
backward.
Release the pedal [2] when the desired adjustment position is
reached.
a
The steering column is set and locked.
