Description
Control stand
42
BA RC50_RC70 en 00
2.02 Control stand
2.02.01 Operating station controls
4
1
2
3
[1] Seat console [2] Steering column
[3] Control panel [4] Drive lever
Cab roof section
9
10
9 4 4 8 7 6 5 4
4 2 1 2 3
[1] Windscreen wiper switch unit [2] Interior lighting
[3] Heating/air-conditioning system switch unit [4] Heating/air-conditioning system ventilation
nozzles
[5] Inside mirror [6] Position for tachograph
[7] Cab fuses [8] Position for radio
[9] Loudspeaker [10] Air intake scoop for air-conditioning system
