Auxiliary equipment
Dozer blade
BA RC50_RC70 en 00
197
6.05 Dozer blade
WARNING
Heavy dozer blade!
Risk of serious injury or death caused by crushing or getting caught
during assembly.
■
Perform assembly work on firm ground (flat, stable, horizontal).
■
Carry out assembly work only when the engine is stopped.
■
Do not perform any assembly or maintenance work on the dozer
blade unless it has been set down.
■
Do not step under a raised dozer blade.
■
Do not step under suspended loads.
6.05.01 Overview
[1] Dozer blade [2] Wearing edge
[3] Hydraulic cylinder [4] Position indicator
6.05.02 Description
The dozer blade is used for stripping and spreading small, loose heaps
and filling in ditches.
After enabling the dozer blade (floating position), the dozer blade
automatically adjusts to uneven ground.
The replaceable wear edge prevents the dozer body from becoming worn
quickly.
