Wacker Neuson RC50 User Manual

Auxiliary equipment
Padfoot shells
BA RC50_RC70 en 00
203
4
31
2
2
[1] Padfoot shells [2] Clamp connection, drum
outside
[3] Clamp connection, drum
centre
[4] Mounting bracket
6.06.02 Description
Using padfoot shells, a smooth drum can be converted into a padfoot
drum. The increase in surface area widens the field of application of the
compactor to cover not only non-cohesive and sandy mixed soils but also
cohesive and highly cohesive soils.
6.06.03 Fitting the padfoot shells
NOTE
If there are foreign objects between the drum and the padfoot
shells, fitting is not possible. Remove any coarse dirt or stones
between the drum and the padfoot shells.
Preparation
Clean the drum and padfoot shells.
Driving the machine onto wooden mounting blocks
100
(4")
100
(4")
1
