4
OPERATING MANUAL
VERSION 05/2017 ORDER NUMBER DOC 2357061
5 DESCRIPTION 23
5.1 Components 23
5.2 Mode of operation 23
5.3 Protective and monitoring equipment 24
5.4 Included items 24
5.5 Data 25
5.5.1 Technical data 25
5.5.1.1 Limitations for 2-circuit systems 28
5.5.2 Dimensions 29
5.5.3 Working areas of ow meters 30
5.5.4 Application limits of ow meters 32
5.6 Mixing types 34
5.7 Dump valve for waste separation (option) 37
5.8 AIS dosing system (option) 37
5.9 2-circuit system 37
5.10 Flow measurement 38
5.10.1 Flow meters 38
5.10.2 Stroke measuring 39
5.10.3 Flow meters and stroke sensors 40
6 ASSEMBLY AND COMMISSIONING 41
6.1 Training of Assembly/Commissioning Sta 41
6.2 Storage and installation conditions 41
6.3 Transportation 41
6.4 Assembly and Installation 41
6.4.1 Electrical connections 43
6.4.2 Pneumatic connections 43
6.4.3 Product connections 43
6.4.4 Flow meter monitoring 44
6.4.5 Lack-of-product protection 44
6.4.6 Ventilation of the spray booth 45
6.5 Grounding 45
6.6 Commissioning 48
6.6.1 Pre-cleaning 48
6.6.2 Initializing the controller 49
6.6.3 Venting the system 50
6.6.4 Pressure tightness test 50
6.6.5 Filling the system 51
6.6.6 Electrostatics 51
7 CONTROLLER 52
7.1 Training the operating sta 52
7.2 Safety instructions 52
7.3 Control cabinet 53
7.3.1 Main switch 53
7.4 Mechanical push-buttons 54
7.5 Operating panel basics 54
7.5.1 Select language 55
7.5.2 Keyboard input 55
7.5.3 Passwords 56
