OPERATING MANUAL
VERSION 05/2017 ORDER NUMBER DOC 2357061
7.6 Home page 56
7.6.1 Changing the paint recipe 56
7.6.2 Home page operation 57
7.7 Menu 58
7.8 Manual mode: open valves 59
7.9 Recipes 60
7.9.1 Add new recipes 60
7.9.2 Changing recipe and valve names 60
7.10 Enter ushing recipe 61
7.11 Enter paint recipe 62
7.12 Calibration 64
7.13 Settings 66
7.13.1 Password level 2 settings 66
7.13.2 Password level 3 settings 69
7.14 Operating panel for 2-circuit system 73
7.14.1 Change uid circuit 73
7.14.2 /K1 and /K2 74
7.14.3 Acknowledge alarms 74
7.14.4 White background: aects both uid circuits 74
8 OPERATION 75
8.1 Training the operating sta 75
8.2 Safety instructions 75
8.2.1 Emergency Deactivation 75
8.2.2 General rules for making adjustments to the spray gun 75
8.3 Switches the system on and o 76
8.4 Malfunction 76
8.5 Spraying mode 77
8.5.1 Prerequisites 77
8.5.2 A/B/C/D pressure ratio 77
8.5.3 Spraying without gun ush box 78
8.5.4 Spraying with gun ush box 79
8.5.5 Interrupting work 79
8.5.6 Changing the paint recipe 79
8.5.7 A valve selection at start 79
8.5.8 Circulation (option) 79
8.6 Flushing 80
8.7 Flow chart with paint recipe change 83
8.8 Pressure relief procedure 84
9 CLEANING AND MAINTENANCE 85
9.1 Cleaning 85
9.1.1 Cleaning sta 85
9.1.2 Safety instructions 85
9.1.3 Filter cleaning 85
9.1.3.1 Condensate drainage from the lter pressure regulator 85
9.1.4 Cleaning the system 86
9.1.5 Decommissioning 86
9.1.6 Long-term storage 86
