WAGNER 2K COMFORT User Manual

6
OPERATING MANUAL
VERSION 05/2017 ORDER NUMBER DOC 2357061
9.2 Maintenance 87
9.2.1 Maintenance sta 87
9.2.2 Safety instructions 87
9.2.3 Gear ow meter 88
9.2.4 Cleaning and replacing the product lter 89
9.2.5 Product valves 89
9.2.6 Product Hoses, Tubes and Couplings 90
10 TROUBLESHOOTING 91
10.1 Alarm messages 93
10.1.1 Fault rectication 98
10.2 Warning messages 105
10.2.1 Fault rectication 106
11 REPAIRS 107
11.1 Repair Sta 107
11.2 Safety instructions 107
11.3 Mounting materials 108
12 DISPOSAL 109
13 ACCESSORIES 110
13.1 Connections 110
13.1.1 I/O extension module 110
13.2 Connection table 2K COMFORT 111
13.3 Control cabinet diagrams 112
13.4 Expansion and accessory sets 112
13.4.1 Installation by customer or by WAGNER service department 113
13.4.1.1 Stroke measuring 115
13.4.2 Installation by WAGNER service department 115
13.4.2.1 AIS 116
13.4.3 Accessories sets for external ushing agent 117
13.5 Remote control (option) 117
13.5.1 Remote control assembling 118
13.5.1.2 Assembly on Control Cabinet 118
13.5.1.3 Testing and Commissioning 118
13.5.2 Safety Instruction Remote Control 119
13.5.3 Operation 120
14 SPARE PARTS 121
15 DECLARATION OF WARRANTY AND CONFORMITY 122
15.1 Important notes on product liability 122
15.2 Warranty claim 122
15.3 EU Declaration of Conformity for 2K COMFORT 123
15.4 EU Declaration of Conformity for 2K COMFORT (with Ex identication) 124
15.5 EC Declaration of Conformity for remote control 125
16 APPENDIX 126
16.1 Conversion of the mixing ratio specications 126
