WAGNER EPG-Sprint X Operating Manual

18
EPG-SPRINT X
OPERATING MANUAL
VERSION 06/2014 ORDER NUMBER DOC2329371
5.2 TECHNICAL DATA
Dimensions:
Height 136 mm; 5.35 inches
Width 270 mm; 10.63 inches
Depth (without operating elements) 200 mm; 7.87 inches
Weight 3.3 kg; 7.28 lbs
Electrical:
Mains (AC) 85 VAC-250 VAC
Frequency 47 Hz-440 Hz
Input power maximum 40 W
Output voltage maximum 22 Vpp
Output current maximum 0.9 A
High-voltage 10-100 kV (adjustable in 1 kV steps)
Corona current limitation 5 µA-120 µA (adjustable in 1 µA steps)
Tribo current measuring range 0 µA-15 µA
Tribo current limitation 0 µA-5 µA (adjustable in 0.1 µA steps)
Tribo current cut o greater than 12 µA
(ATEX: switching o of the unit)
Protection class: IP 64
Ex zone II 3(2)D 80 °C; 176 °F (Zone 22)
Pneumatic:
Air input pressure 0.6-0.8 MPa; 6-8 bar; 87-116 psi
Air volume maximum 15 m³/h
Sum of dosing and feed air 1-6 m³/h
Gun air 0.05-4.0 m³/h
Required compressed air quality as per ISO8573.1 3.5.2
Connection hose diameter 8 mm; 0.315 inches
Ambient conditions:
Operating temperature range 5-45 °C; 41-113 °F

WAGNER EPG-Sprint X Specifications

General

Brand	WAGNER
Model	EPG-Sprint X
Category	Control Unit
Language	English
