6.4 CONNECTING THE MANUAL GUN
Mains input terminal
Grounding cable to the signal ground
e.g., from the powder tank
Compressed air main supply
(0.6-0.8 MPa; 6-8 bar; 87-116 psi)
Hose diameter:
8 mm; 0.315 inches
Powder injector
Dosing air, blue
Feed air, red
Powder feed, transparent
Atomizing or Tribo air,
transparent
Electrical connection cable
Corona or Tribo spray gun
EPG-SPRINT X
